Condens 2300 W condensing boiler

Maximum efficiency and silence in the minimum space

• Suitable for: single and multi-family houses, condominium apartments


• Ideal for replacements and renovations


• Wall-mounted boiler

Advantages

First-class reliability

Condens 2300 W stands out for its essential design and compact dimensions, which make it the ideal solution for any context. Robustness and reliability are guaranteed by the primary exchanger in Al-Si WB6 aluminum alloy.

Modulation ratio 1:10

The modulation ratio reaches up to 1:10 and is constant over time thanks to the modulation system without mechanical parts. This ensures significant gas savings and maximum comfort, even with low domestic water demands.

Maximum seasonal yield

Condens 2300 W reaches a seasonal efficiency of 94%, the maximum for a condensing boiler. In combination with a modulating thermoregulator, it is possible to reach energy efficiency class A+.

Details and technical documents

Type name: GC2300W 24/30 C 23

Min. rated heat output (80/60 °C): 3 kW

Max. rated heat output (50/30 °C): 25 kW

At 30% of rated heat output and low temperature regime: 8.0 kW

Max. rated heat load heating: 24.5 kW

Electrical connection: 230 V

Electrical frequency: 50 Hz

Protection type (EN 60529): "IPX4D, B23/B33

Max. consumption of electricity: 110 W

Net weight: 39kg

Nominal heat output: 24 kW

Seasonal space heating energy efficiency: 94%

Water heating energy efficiency: 85%

Product code: 7736901286
